Strymon PCH X1 Active DI Isolator

This new DI box will ship insured and inspected from our Rapid City, SD location.

Buy risk free with our 14 day - full refund, less shipping, return policy.  Check out our shop policies for more details.

Pristine Audio Clarity: Strymon PCH X1 Active DI Isolator at Haggerty's Music

Don't let signal degradation ruin your performance. Available now at Haggerty's Music, the Strymon PCH X1 Active DI Isolator is the ultimate tool for musicians and sound engineers who demand absolute sonic purity. Whether you are plugging in an acoustic guitar, a vintage bass, or a modern synthesizer, this active direct box ensures your tone reaches the mixing console exactly as intended.

Engineered with a massive 2 MΩ input impedance, the PCH X1 captures every nuance of your instrument without loading down its natural tone. It delivers a staggering frequency response and an ultra-low noise floor (-123 dBu), guaranteeing that your signal remains transparent, uncolored, and free from unwanted harmonic distortion.

Need to clean up a muddy mix? The selectable High-Pass Filter (80Hz, 240Hz) makes it easy to eliminate low-end rumble right at the source. Powered by standard +48V phantom power and housed in an ultra-compact chassis, the Strymon PCH X1 is the perfect, stage-ready solution for maintaining studio-grade audio in any environment.

Why You'll Love It:

• Uncolored Tone: A 2 MΩ input impedance preserves the natural high-end and dynamic feel of your pickups without loading down your signal.
• Studio-Grade Transparency: Exceptionally low Total Harmonic Distortion (0.0007% at 1kHz) and a -123 dBu noise floor keep your sound crystal clear.
• Built-in Rumble Control: Features an integrated High-Pass Filter (HPF) at 80Hz or 240Hz to easily cut out unwanted low frequencies.
• Gig-Ready & Compact: Measures just 3.66″ long and runs on standard 48V phantom power, easily fitting into any gig bag or pedalboard setup.

Technical Specifications:

Input & Thru

• Input Impedance: 2 MΩ
• Max Input Level: +20.5dBu
• Thru Gain Relative to Inputs: +0dB
• Thru Output Impedance: 0Ω

XLR Out & Audio Performance

• Output Impedance: 100 Ω
• Gain Relative to Inputs: -20dB
• Maximum Output Level: +0.5dBu
• Noise Floor: -123 dBu (10-22kHz no A-Weight)
• Frequency Response (HPF off):
• +/- 0.25dB, 20Hz – 30kHz (13.6KΩ load)
• +/- 0.5dB, 10Hz – 80kHz (13.6KΩ load)
• +/- 0.5dB, 20Hz – 20kHz (600Ω load)
• Filter: HPF (80Hz, 240Hz)
• Total Harmonic Distortion & Noise (-10dBu out):
• 1kHz: 0.0007%
• 100Hz: 0.0035%
• 50Hz: 0.0125%

Power & Dimensions

• Power Requirements: 5mA @ +48VDC
• Dimensions: 3.66″ L (93mm) x 1.97″ W (50mm) x 1.54″ H (39mm)

Protect your tone and transform your live or studio performance. Get the Strymon PCH X1 Active DI Isolator today at Haggerty's Music!
